旋轉閥/卸料閥的工作原理主要涉及電動機驅動減速機，通過聯軸器或鏈輪使旋轉閥的轉子旋轉。在旋轉過程中，材料位于旋轉葉片的空間內，葉片的旋轉將材料帶到排出口，材料的自重使其流入輸送系統或儲藏室。這種工作方式使得卸料閥能夠均勻、連續地向輸料管供料，保證氣力輸出管內的氣體和固體物質保持穩定，從而確保氣力輸送系統的正常工作。同時，卸料閥還具有鎖氣作用，能夠隔斷卸料閥上下部的氣壓。?【電話/微信咨詢：陳經理18068546632】

內襯四氟旋轉閥基本介紹：

四氟是一種化學性穩定、具有優異的耐高溫、耐低溫和不粘附性的高分子材料，可以在極端的化學環境下使用。四氟內襯是在金屬、陶瓷等材料表面制成的一種覆蓋層，主要用于防腐、防粘附和減少摩擦。

內襯四氟旋轉閥作用：

耐高溫性：四氟旋轉閥卸料閥具有出色的耐高溫性能，能夠在高溫環境下保持穩定的工作狀態。它適用于化工反應過程中產生的高溫介質的控制和調節，確保旋轉閥的密封性和流體的穩定輸送。【電話/微信咨詢：陳經理18068546632】

防粘附作用：四氟旋轉閥表面具有良好的不粘附性，能夠防止設備表面附著物的黏附，避免管道物料：粉體/顆粒料在長期運行過程中出現結垢、石灰積垢等現象，從而提高了設備的效率。

            《掃二維碼-添加 陳經理 微信-咨詢產品》

The working principle of a rotary valve/discharge valve mainly involves an electric motor driving a reducer, which rotates the rotor of the rotary valve through a coupling or sprocket. During the rotation process, the material is located in the space of the rotating blades, and the rotation of the blades brings the material to the discharge outlet. The self weight of the material causes it to flow into the conveying system or storage room. This working method enables the discharge valve to uniformly and continuously feed the conveying pipe, ensuring that the gas and solid substances in the pneumatic output pipe remain stable, thereby ensuring the normal operation of the pneumatic conveying system. At the same time, the discharge valve also has a locking effect, which can block the air pressure at the upper and lower parts of the discharge valve. ?

Introduction to PTFE lined rotary valve:

Tetrafluoroethylene is a chemically stable polymer material with excellent resistance to high and low temperatures and non adhesiveness, which can be used in extreme chemical environments. PTFE lining is a covering layer made on the surface of metal, ceramic and other materials, mainly used for corrosion prevention, anti adhesion and reducing friction.

Function of PTFE lined rotary valve:

High temperature resistance: The PTFE rotary valve discharge valve has excellent high temperature resistance and can maintain a stable working state in high temperature environments. It is suitable for controlling and regulating high-temperature media generated in chemical reaction processes, ensuring the sealing of rotary valves and stable fluid transport.

Anti adhesion effect: The surface of the PTFE rotary valve has good non adhesion, which can prevent the adhesion of surface attachments and avoid scaling and lime accumulation of pipeline materials such as powder/particle materials during long-term operation, thereby improving the efficiency of the equipment.
